Allen Bradley 100-C09KA400 9 Amp IEC Contactor
$119.00/ea
Usually available within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 100-C09KA400
NorthEast Part # 789355

Specifications

Contactor Data

  • Terminal Type: Screw Terminals
  • Rated Operating Current, AC-3: 9A
  • Coil Voltage: 240V 50/60Hz
  • No. of Poles: 4 Poles
  • Coil Termination: Line Side
  • Contact Configuration: 4 N.O. 0 N.C. Main Contact Configuration
  • Package Quantity: 1

Application Data

  • Electrical Standards: UL

Load Data [Optional]

  • Utilization Category: AC-3 Squirrel-cage motor starting and stopping

Life Data [Optional]

  • Actual Life: Actual Life Cannot be Calculated (more information)...

Terminal Marking Positions Used

  • 100-C or 104-C Contactor: None
  • Front Mounted Auxiliary Contact: None
  • Left Side Auxiliary Contact: None
  • Right Side Auxiliary Contact: None
  • Interlock: None

Overview

UPC 66246890258
Product Description IEC 9 A Contactor
GTiN 00662468902588
Terminal Type Screw Terminals
Coil Voltage 240 VAC at 50/60 Hz
Family Brand Name Allen Bradley
Current 9 A
Number of Poles 4 Pole
Conductor Size 16-10 AWG
Mounting Type Panel or 35 mm DIN Rail
Temperature Rating -25 to 60 C
Power Rating 3 kW at 230 V, 4 kW at 400/415 V, 500 V and 690 V
Contact Configuration 4 NO Main
Blade Dimensions 1-25/32 in W x 3-11/64 in D x 3-3/16 in H
Environmental Conditions -55 to 80 deg C Storage Temperature, IEC 60068-2-1/-2/-30 Climatic Withstand, 2000 m Maximum Altitude of Installation Site
