Allen Bradley 100-D115EZJ00 115 Amp MCS D IEC Contactor
$924.00/ea
Usually available within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 100-D115EZJ00
NorthEast Part # 769831

Specifications

  • 3-Phase kW (50 Hz) 690V Rating: 110
  • Coil Voltage: 24V DC Electronic Coil w/ Elec. Interface
  • 3-Phase kW (50 Hz) 415V Rating: 66
  • 3-Phase HP (60 Hz) 200V Rating: 40
  • 3-Phase kW (50 Hz) 400V Rating: 63
  • 3-Phase HP (60 Hz) 575V Rating: 100
  • 3-Phase kW (50 Hz) 500V Rating: 80
  • Rated Operating Current: 115 A
  • 3-Phase HP (60 Hz) 460V Rating: 75
  • 3-Phase kW (50 Hz) 230V Rating: 37
  • Coil Type: Electronic Coil w/ Electronic Interface
  • 3-Phase HP (60 Hz) 230V Rating: 40
  • 3-Phase kW (50 Hz) 1000V Rating: 63
  • Auxiliary Contact Configuration: 0 N.O. 0 N.C.

Categories

Overview

UPC 88563002925
Product Description IEC 115 A MCS D Contactor
GTiN 00885630029252
Type Non-Reversing
Coil Voltage 24 VDC
Family Brand Name Allen Bradley
Contact Configuration 0 N.O. 0 N.C.
Current 115 A
Sub Brand IEC
Conductor Size 6 AWG - 300 MCM
Temperature Rating -25 to 60 C
Power Rating 37 kW at 230 V, 63 kW at 400 V, 66 kW at 415 V, 80 kW at 500 V, 110 kW at 690 V, 63 kW at 1000 V, 40 kW at 200 V
Blade Dimensions 120 mm L x 156 mm W x 170 mm H
Environmental Conditions -40 to 80 C Storage, IEC 60068-2-27 Resistance to Shock, IEC 60068-2-6 Resistance to Vibration, 2000 NN Per IEC 60947-4 Maximum Altitude Of Installation Site, IEC 60068-2-30 Climatic Withstand
Number of Poles 3 Pole
Standard C-TICK
Number of Phases 3 Phase
