Allen Bradley 100-D115H11 115 Amp MCS D IEC Contactor
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$709.00/ea
Usually available within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 100-D115H11
NorthEast Part # 829432

Specifications

  • Coil Voltage: 208V 60Hz
  • 3-Phase kW (50 Hz) 230V Rating: 37
  • 3-Phase kW (50 Hz) 400V Rating: 63
  • 3-Phase kW (50 Hz) 415V Rating: 66
  • 3-Phase kW (50 Hz) 500V Rating: 80
  • 3-Phase kW (50 Hz) 690V Rating: 110
  • 3-Phase kW (50 Hz) 1000V Rating: 63
  • 3-Phase HP (60 Hz) 200V Rating: 40
  • 3-Phase HP (60 Hz) 230V Rating: 40
  • 3-Phase HP (60 Hz) 460V Rating: 75
  • 3-Phase HP (60 Hz) 575V Rating: 100

System Voltage Data

  • Phases: Three Phase

Contactor Data

  • Rated Operating Current: 115 A
  • Coil Type: Conventional Coil
  • Control Voltage: 208V 60Hz
  • Auxiliary Contact Configuration: 1 N.O. 1 N.C.

Overview

UPC 88563018779
Product Description IEC 115 A MCS D Contactor
GTiN 00885630187792
Type MCS D, Non-Reversing
Standard C-TICK,CCC
Coil Voltage 208 VAC at 60 Hz
Control Voltage 208 V
Family Brand Name Allen Bradley
Number of Phases 3 Phase
Contact Configuration 1 NO - 1 NC Auxiliary
Current 115 A
Sub Brand IEC
Conductor Size 6 AWG - 300 MCM
Mounting Type Panel
Temperature Rating -25 to 60 C
Power Rating 37 kW at 230 V, 63 kW at 400 V, 66 kW at 415 V, 80 kW at 500 V, 110 kW at 690 V, 63 kW at 1000 V
Blade Dimensions 120 mm W x 156 mm D x 170 mm H
Environmental Conditions -40 to 80 deg C Storage Temperature, IEC 60068-2-30 Climatic Withstand, 2000 NN m, per IEC60947-4 Maximum Altitude of Installation Site
Number of Poles 3 Pole
