Allen Bradley 100-D180EN11 180 Amp MCS D IEC Contactor
$1,850.00/ea
Usually available within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 100-D180EN11
NorthEast Part # 880787

Specifications

  • 3-Phase kW (50 Hz) 230V Rating: 57
  • 3-Phase kW (50 Hz) 1000V Rating: 90
  • Rated Operating Current: 180 A
  • 3-Phase HP (60 Hz) 460V Rating: 150
  • 3-Phase kW (50 Hz) 500V Rating: 100
  • Coil Voltage: 380-415V 50/60Hz / 440-480V 50/60Hz / 500V 50/60Hz Electronic Coil w/ Elec. Interface
  • Auxiliary Contact Configuration: 1 N.O. 1 N.C.
  • 3-Phase kW (50 Hz) 690V Rating: 135
  • 3-Phase kW (50 Hz) 415V Rating: 105
  • Coil Type: Electronic Coil w/ Electronic Interface
  • 3-Phase HP (60 Hz) 200V Rating: 50
  • 3-Phase HP (60 Hz) 230V Rating: 60
  • 3-Phase HP (60 Hz) 575V Rating: 150
  • 3-Phase kW (50 Hz) 400V Rating: 101

Overview

UPC 78118010345
Product Description IEC 180 A MCS D Contactor
GTiN 00781180103452
Type MCS D, Non-Reversing
Coil Voltage 380 - 500 VAC at 50/60 Hz
Family Brand Name Allen Bradley
Contact Configuration 1 NO - 1 NC Auxiliary
Current 180 A
Sub Brand IEC
Conductor Size 6 AWG - 300 MCM
Mounting Type Panel
Temperature Rating -25 to 60 C
Power Rating 55 kW at 230 V, 90 kW at 400 V, 415 V, 110 kW at 500 V, 90 kW at 690 V, 132 kW at 1000 V
Blade Dimensions 120 mm W x 156 mm D x 170 mm H
Environmental Conditions -40 to 80 deg C Storage Temperature, IEC 60068-2-30 Climatic Withstand, 2000 NN m, per IEC60947-4 Maximum Altitude of Installation Site
Number of Poles 3 Pole
