Allen Bradley 100-D250EZJ11 250 Amp MCS D IEC Contactor
$2,740.00/ea
Usually available within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 100-D250EZJ11
NorthEast Part # 783346

Specifications

  • Coil Voltage: 24V DC Electronic Coil w/ Elec. Interface
  • Auxiliary Contact Configuration: 1 N.O. 1 N.C.
  • Coil Type: Electronic Coil w/ Electronic Interface
  • 3-Phase HP (60 Hz) 460V Rating: 200
  • 3-Phase HP (60 Hz) 200V Rating: 75
  • 3-Phase kW (50 Hz) 1000V Rating: 132
  • 3-Phase kW (50 Hz) 415V Rating: 145
  • 3-Phase kW (50 Hz) 690V Rating: 250
  • 3-Phase kW (50 Hz) 500V Rating: 177
  • 3-Phase HP (60 Hz) 230V Rating: 100
  • 3-Phase HP (60 Hz) 575V Rating: 250
  • 3-Phase kW (50 Hz) 400V Rating: 140
  • 3-Phase kW (50 Hz) 230V Rating: 80
  • Rated Operating Current: 250 A

Overview

UPC 78118002978
Product Description IEC 250 A MCS D Contactor
GTiN 00781180029783
Type MCS D, Non-Reversing
Coil Voltage 24 VDC
Family Brand Name Allen Bradley
Contact Configuration 1 NO - 1 NC Auxiliary
Current 250 A
Sub Brand IEC
Conductor Size (2) 4 AWG - 350 MCM
Mounting Type Panel
Temperature Rating -25 to 60 C
Power Rating 80 kW at 230 V, 140 kW at 400 V, 150 kW at 415 V, 250 kW at 500 V, 690 V, 132 kW at 1000 V
Blade Dimensions 155 mm W x 205 mm D x 180 mm H
Environmental Conditions -40 to 80 deg C Storage Temperature, IEC 60068-2-30 Climatic Withstand, 2000 NN m, per IEC60947-4 Maximum Altitude of Installation Site
Number of Poles 3 Pole
