Allen Bradley 100-D300EA11 300 Amp MCS D IEC Contactor
$2,470.00/ea
Usually available within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 100-D300EA11
NorthEast Part # 592730

Specifications

  • Coil Voltage: 208-277V 50/60Hz / 200-255V DC Electronic Coil w/ Elec. Interface
  • 3-Phase kW (50 Hz) 230V Rating: 97
  • 3-Phase kW (50 Hz) 400V Rating: 170
  • 3-Phase kW (50 Hz) 415V Rating: 176
  • 3-Phase kW (50 Hz) 500V Rating: 213
  • 3-Phase kW (50 Hz) 690V Rating: 300
  • 3-Phase kW (50 Hz) 1000V Rating: 160
  • 3-Phase HP (60 Hz) 200V Rating: 100
  • 3-Phase HP (60 Hz) 230V Rating: 125
  • 3-Phase HP (60 Hz) 460V Rating: 250
  • 3-Phase HP (60 Hz) 575V Rating: 300

System Voltage Data

  • Phases: Three Phase

Contactor Data

  • Rated Operating Current: 300 A
  • Coil Type: Electronic Coil w/ Electronic Interface
  • Control Voltage: 208-277V 50/60Hz
  • Auxiliary Contact Configuration: 1 N.O. 1 N.C.

Features

  • Includes reversible coil terminations (line or load side)
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • Includes space-saving coil-mounted control modules
  • Provides front and side mounting of auxiliary contacts
  • Provides reversible coil terminations (line or load side)
  • Includes built-in surge suppression
  • Meets IEC, UL, and CSA standards requirements
  • Includes electronic and pneumatic timing modules
  • Available integrated PLC interface
  • Provides IP2X finger protection
  • Offers common accessories for all contactor sizes
  • Simplifies selection with electronic wide-range AC/DC coils
  • Saves energy with low power consumption
  • RoHs compliant
  • Complies with RoHs

Overview

UPC 78118010533
Product Description IEC 300 A MCS D Contactor
GTiN 00781180105333
Type Non-Reversing
Standard CE,CSA,UL,KC,C-TICK,CUL
Coil Voltage 208 - 277 VAC at 50/60 Hz
Control Voltage 208/277 V
Family Brand Name Allen Bradley
Number of Phases 3
Contact Configuration 1 NO, 1 NC Auxiliary
Current 300 A
Sub Brand IEC
Conductor Size 4 AWG - 350 MCM
Temperature Rating -25 to 60 C
Power Rating 90 kW at 230 V, 170 kW at 400 V, 160 kW at 415 V, 290 kW at 500 V, 300 kW at 690 V, 160 kW at 1000 V, 100 kW at 200 V
Environmental Conditions -40 to 80 C Storage, IEC 60068-2-27 Resistance to Shock, IEC 60068-2-6 Resistance to Vibration, 2000 NN Per IEC 60947-4 Maximum Altitude Of Installation Site, IEC 60068-2-30 Climatic Withstand
Number of Poles 3 Pole
