Allen Bradley 100-K12ZQ300 12 Amp IEC Miniature Contactor
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$174.00/ea
Usually available within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 100-K12ZQ300
NorthEast Part # 1024051

Features

  • Compact size
  • Same dimensions for AC and DC
  • IP2X finger protection
  • Full-voltage non-reversing and reversing contactors
  • Mirror contacts per IEC 60947-4-1 and mechanically linked contacts per IEC 60947-5-1 on main unit
  • Compatible with Bulletin 193-K bimetallic overload relay
  • Optional integrated surge suppressor

Specifications

  • Connection: Screw Type Terminals
  • Contactor Size: 12 A
  • 3-Phase kW (50 Hz) 400V/415V Rating: 5.5
  • 3-Phase kW (50 Hz) 500V Rating: 5.5
  • 3-Phase kW (50 Hz) 690V Rating: 5.5
  • 1-Phase HP (60 Hz) 115V Rating: 0.75
  • 3-Phase HP (60 Hz) 460V Rating: 7.5
  • 3-Phase HP (60 Hz) 575V Rating: 7.5
  • Coil Voltage: 12 (7.5...15)V DC

Contactor Data

  • Terminal Type: Screw Type Terminals
  • Rated Operating Current: 12 A
  • Control Voltage: 12 (7.5...15)V DC
  • No. of Poles: 4 Poles
  • Main Contact Configuration: 3 N.O./ 1 N.C.
  • Package Quantity: 1

Overview

UPC 66207449615
Product Description IEC 12 A Miniature Contactor
GTiN 00662074496150
Type Miniature Contactor
Terminal Type Screw Terminals
Connection Type Screw Type Terminals
Coil Voltage 12 V
Control Voltage 12 V
Family Brand Name Allen Bradley
Contact Configuration None,3 N.O./ 1 N.C. Poles
Current 12 A
Contact Rating 12 A
Number of Poles 4 Pole
Sub Brand IEC
Contactor Size 12 A
Standard CCC
