Allen Bradley 104-C43KD22 43 Amp Reversing IEC Contactor
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$742.00/ea
Usually available within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 104-C43KD22
NorthEast Part # 204820

Specifications

Assembly

  • Factory or User Assembled?: Factory Assembled

Contactor Data

  • Terminal Type: Screw Terminals
  • Rated Operating Current, AC-3: 43A
  • Coil Voltage: 110V 50/60Hz
  • Coil Termination: Line Side
  • Auxiliary Contact Configuration: 1 N.O. 1 N.C.

Application Data

  • Electrical Standards: UL

Load Data [Optional]

  • Utilization Category: AC-3 Squirrel-cage motor starting and stopping

Life Data [Optional]

  • Actual Life: Actual Life Cannot be Calculated (more information)...

Additional Information

  • Notice: See Pub. 0100C-1.0.1 for additional electrical life information.

Terminal Marking Positions Used

  • 100-C or 104-C Contactor: 1_, 4_
  • Front Mounted Auxiliary Contact: None
  • Front Mounted Auxiliary Contact (Right Side if 104C): None
  • Left Side Auxiliary Contact: None
  • Right Side Auxiliary Contact: None
  • Interlock: 2_

Overview

UPC 61132010444
Product Description IEC 43 A Reversing Contactor
GTiN 00611320104448
Type Reversing
Terminal Type Screw Terminals
Coil Voltage 110 VAC at 50/60 Hz
Family Brand Name Allen Bradley
TC Connection Screw Terminals
Contact Configuration 1 NO, 1 NC Auxiliary
Current 43 A
Sub Brand IEC
Conductor Size 14 - 4 AWG
Mounting Type Panel or 35 mm DIN Rail
Temperature Rating -25 to 60 C
Power Rating 13 kW at 230 V, 22 kW at 400/415 V, 25 kW at 500 V and 22 kW at 690 V
Blade Dimensions 2-1/8 in W x 3-3/16 in H x 3-61/64 in D
Environmental Conditions -55 to 80 C Storage, IEC 60068-2-1/-2/-30 Climatic Withstand, 2000 m NN, per IEC60947-1 Maximum Altitude of Installation Site
Standard C-TICK,CCC,KC
Connection Type Screw Terminals
