Allen Bradley 104-K05ZJ02 IEC Miniature Reversing Contactor
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$281.00/ea
Usually available within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 104-K05ZJ02
NorthEast Part # 578869

Specifications

  • Connection: Screw Type Terminals
  • Coil Voltage: 24 (17...30)V DC
  • kW, 230V (50 Hz) 3-Phase: 1.5
  • kW, 400/415V (50 Hz) 3-Phase: 2.2
  • kW, 500V (50 Hz) 3-Phase: 2.2
  • kW, 690V (50 Hz) 3-Phase: 2.2
  • Hp, 200V (60 Hz) 3-Phase: 1.5
  • Hp, 230V (60 Hz) 3-Phase: 1.5

Assembly

  • Factory or User Assembled?: Factory Assembled

System Voltage Data

  • Phases: 3 Phase

Contactor Data

  • Terminal Type: Screw Type Terminals
  • Rated Operating Current: 5 A
  • Control Voltage: 24 (17...30)V DC
  • No. of Poles: 3 Poles
  • Main Contact Configuration: 3 N.O.
  • Auxiliary Contact Configuration (Per Contactor): 1 N.C.

Overview

UPC 66207449744
Product Description IEC Miniature Reversing Contactor
GTiN 00662074497447
Type Reversing
Terminal Type Screw Terminals
Connection Type Screw Type Terminals
Coil Voltage 24 VDC
Control Voltage 24 V
Family Brand Name Allen Bradley
Number of Phases 3 Phase
Contact Configuration 3 NO Main, 1 NC Auxiliary
Current 5 A
Contact Rating 5 A
Number of Poles 3 Pole
Sub Brand IEC
Temperature Rating -25 to 60 C
Power Rating 1.5 kW at 230 V, 2.2 kW at 400/415 V, 2.2 kW at 500 V, 2.2 kW at 690 V
Environmental Conditions -55 to 80 C Storage, IEC60068-2 Resistance to Shock, IEC60068-2 Resistance to Vibration
Standard CCC,KC
